STIHL Quick Chain tensioning
RE-TENSION THE SAW CHAIN TOOL-FREE. Thanks to STIHL Quick Chain Tensioning, you can tension your saw chain quickly and without tools, thanks to the adjusting wheel. Turning the adjusting wheel to the left releases tension on the saw chain, and turning the adjustment wheel to the right tensions the saw chain. The guide bar will be automatically secured when you tighten the sprocket cover.
Soft grip handle with ergo lever
Thanks to the soft grip handle, this tool fits comfortably in your hand. Plus, the grip helps to use the tool in wet weather.
Two-handed operation
ENSURES COMFORTABLE WORK. Your STIHL chainsaw has an ergonomically shaped handle and a comfortable rear control handle with soft components. Thanks to this two-handed operation, you can work comfortably, effortlessly and safely in all positions.
Transparent oil tank
MAKES FILL-LEVEL MONITORING EASY. With the transparent oil tank, you can easily and quickly check the fill level of the chain oil. This means that you always know when you need to add chain oil for efficient work over long periods.
EC motor
LOW-MAINTENANCE AND EFFICIENT. Thanks to its compact design, low weight and high efficiency, the EC motor enables you to work in an energy efficient manner. This engine also has a long service life.
Tool-free oil tank
Thanks to the soft grip on the control handle, the chainsaw sits comfortably in the hand and can be operated safely. In addition, the users grip is improved by the soft material, which helps when using the chainsaw in wet conditions.
Soft-grip control handle
Thanks to the soft grip on the control handle, the chainsaw sits comfortably in the hand and can be operated safely. In addition, the users grip is improved by the soft material, which helps when using the chainsaw in wet conditions.
Constant power
When using other brands of battery tools, the performance can sometimes decrease during work as the battery discharges. This isn't the case with STIHL battery-powered tools. Thanks to the intelligent electronics, your tool will work with consistently high power across the entire battery charge, until there is no energy left in the battery.
Technical details
Rated voltage |
36 V |
Power |
0.7 kW |
Battery system |
AK |
Recommended battery |
AK 20 |
Weight |
2.5 kg |
Saw chain pitch |
1/4"P |
IPX Rating |
N/A |
Battery working time AK 10 (Power level 1) |
up to 18 min 1) |
Battery working time AK 20 (Power level 1) |
up to 40 min 1) |
Battery working time AK 30 S (Power level 1) |
up to 55 min 1) |
Length with bumper strike |
451 mm |
Sound pressure level |
83 dB(A) 2) |
Sound power level |
91 dB(A) 3) |
Vibration levels left/right |
3.2/3.4 m/s² 4) |
