ARIENS Apex Series Zero-turn Mowers
Apex 48
Apex 48 R
Apex 52
Apex 52 R
Commercial-grade zero-turns, designed for all-day, every day use.
GET ON TOP OF YOUR GAME WITH APEX
The Ariens APEX quickly established as THE standard commercial zero-turn across Europe. It performs without compromise no matter how tough the conditions. Meticulously designed to provide exceptional cut quality, it still remains simple and comfortable to operate and can be configured with ROPS and a rear discharge deck to cater for almost any individual requirement
Curved tubular steel frame
The frame, made entirely of tubular steel, forms the skeleton of the mower. It bears the entire load of the machine for many years and must be able to cope with shocks and vibrations over the long term. State-of-the-art bending technology avoids weak points due to welded joints.
Professional mowing deck
The mowing deck is the most heavily loaded component of a mower. Stability is particularly important here. The APEX has a 14 cm deep, fully welded mower deck made of 3.2 mm thick sheet steel with double spindle supports, 12.7 mm steel edge, enclosed anti-scalp wheels, all-steel pulleys, welded 4-point suspension and high-quality blade spindles made of forged aluminium. Everything about it is designed for a long service life.
Automatic belt tensioner system
The automatic CBT (Constant Belt Tension) technology keeps the belt tension of the mower deck constant at all times. This increases the service life of the belt, compensates for wear and prevents belt slippage for a consistently high-quality cutting pattern.
Mower deck lifting by foot pedal
The solid cutting deck is raised conveniently and effortlessly using a foot pedal. To select one of the 15 cutting heights from 3.8 - 12.7 cm, a metal plug is inserted into the respective recess in the display.
Easy access to the mowing deck
The mowing deck is easy to access from above for cleaning and maintenance. Thanks to CBT technology, changing the belt takes just a few minutes. Simply slacken the tensioning pulleys, thread in the belt, tension the tensioning pulleys again - done.
Padded seat and armrests
The soft, adjustable seat with high backrest is equipped with padded armrests for greater comfort even during long periods of mowing. Coil spring damping absorbs shocks on uneven surfaces.
Contact us for latest prices, sales and service:
01295 211 790
Ariens Apex 48 Zero Turn Mower
991324
ARIENS Apex 48R Zero Turn Mower
991325
ARIENS Apex 52 Zero-turn Mower
991326
ARIENS Apex 52R Zero-turn Mower
991327
